August 29, 2019
Feature

This Dispatch Delivers Good Energy News

PNNL demonstrates a new approach with benefits all around

Economic dispatch can incorporate renewables and energy storage with the grid

Field testing of PNNL’s Economic Dispatch technology has demonstrated that the approach can effectively and economically coordinate CHP units, building operations, energy costs, and other factors to deliver benefits in energy efficiency, grid resiliency, and clean energy.

A promising Pacific Northwest National Laboratory-developed technology optimizes the operation of large heating and cooling units that also generate electricity. This advance could be key in bringing more clean, renewable energy onto the power grid.

The automated technology, which also could save energy and enhance grid reliability, successfully enabled “Economic Dispatch” during a recent multi-month field test at a New York energy provider’s plant. “This result represents a step forward in establishing next-generation integrated energy systems,” says PNNL’s Srinivas Katipamula, a mechanical engineer who led technology development efforts.

Economic Dispatch: A Novel Energy Approach

Economic Dispatch is a concept that links a combined heating, cooling, and power system (CHP) with a building’s operational systems and the power grid, while concurrently monitoring a range of factors that impact electricity supply and demand. These factors include weather conditions, local energy consumption, and current electricity costs.

The goal of Economic Dispatch is to coordinate all of these various elements in a manner that optimizes CHP generation, keeps the building completely functional (occupants warm or cool, etc.), and contributes to reliable and resilient grid operations. A more resilient grid then has increased flexibility to incorporate intermittent renewables, such as wind power, which can disrupt grid operations due to sudden starts or stops in generation based on weather.

“Ideally, the CHP is operating so effectively under Economic Dispatch that it can meet all needs and earn more income than usual from selling its excess electricity to the grid,” Katipamula says. “With CHP prevalence expected to grow significantly over time, Economic Dispatch capabilities can render these units as key assets in meeting multiple energy, environmental, and economic needs.”

The technology designed and developed by PNNL for Economic Dispatch represents a cost and performance breakthrough that’s highly appealing to CHP owners/operators. The technology’s supervisory controller—the open source VOLTTRON™ distributed control and sensing software platform—can be deployed from a low-cost (less than $200) computing resource or from the Cloud. PNNL-crafted Economic Dispatch algorithms are launched from the platform to the CHP and associated building systems. This fully-automated approach, which includes data collection and analysis capabilities, then optimally weighs multiple factors and makes decisions related to CHP production and building energy needs, while communicating and coordinating with power grid operations.

Putting It to the Test

The VOLTTRON™-based Economic Dispatch system deployment and testing were initiated in late fall 2018 in Utica, New York, at Burrstone Energy Corporation’s CHP plant, which contains four natural-gas-fueled units serving a college, hospital, and nursing home. PNNL’s system proved relatively easy to configure and deploy. Once operational, the system established and evaluated operation strategies, sending commands to the CHPs regarding whether the units should run and the modes they should operate in. Testing was conducted and concluded in spring 2019, with several key outcomes:

  • The automated system successfully dispatched control signals to the CHP.
  • A benchmarking analysis, which examined a few days of operation in March and compared the Economic Dispatch system to the previous CHP control method, demonstrated savings on the order of $50 per day. This equates to $20,000 per year in additional profit from a CHP.
  • Preliminary results strongly suggest the system can be deployed in the field and customized at lower cost than existing options.
  • A New York-based energy services provider that supported the project, Frontier Energy, was impressed with the technology and adopted the Economic Dispatch tool for its customers.

The testing also yielded lessons learned that will inform future advancements in automated Economic Dispatch. Extended testing will continue through summer 2019.

The technology development was funded through the U.S. Department of Energy (DOE) Building Technologies office as part of DOE’s Grid Modernization Laboratory Consortium.

###

About PNNL

Pacific Northwest National Laboratory draws on its distinguishing strengths in chemistry, Earth sciences, biology and data science to advance scientific knowledge and address challenges in sustainable energy and national security. Founded in 1965, PNNL is operated by Battelle for the Department of Energy’s Office of Science, which is the single largest supporter of basic research in the physical sciences in the United States. DOE’s Office of Science is working to address some of the most pressing challenges of our time. For more information, visit https://energy.gov/science. For more information on PNNL, visit PNNL's News Center. Follow us on Twitter, Facebook, LinkedIn and Instagram.

Published: August 29, 2019

PNNL Research Team

Srinivas Katipamula
Di Wu
Nick Fernandez
Lee Burke
Thiagarajan Ramachandran
