April 30, 2024
Research Highlight

Horizontal Resolution Affects Model Aerosol Properties

Earth system model with regional refinement over the U.S. produces different aerosol sources and sinks and aerosol-cloud interactions compared to the global low-resolution model

Large clouds sweep over a open, wet field of grass and trees

The finer model horizontal resolution produces larger cloud liquid water content and resolves more large-scale precipitation, leading to improved aqueous-phase production of sulfate and aerosol wet scavenging by large-scale precipitation. In contrast, less convective precipitation is parameterized in the high-resolution model, reducing aerosol wet scavenging by convective precipitation.

(Image: ncas.ac.uk)

The Science

Earth system models are running at higher resolutions. Yet parameterizations designed to represent aerosol lifecycles and their interactions with clouds and radiation in the Energy Exascale Earth System Model (E3SM) are developed and evaluated at Earth system model scales, and their performance at higher resolution is unclear. Researchers evaluated the sensitivity of aerosol properties to horizontal grid spacing in E3SM version 1 by comparing simulation results from the low-resolution (~100 km) model and the regional refinement model (RRM) with high-resolution (~25 km) meshes over the United States. They found horizontal resolutions can alter the simulated aerosol mass budget, aerosol–cloud interactions, and the effective radiative forcing of anthropogenic aerosols.

The Impact

This is the first study to comprehensively evaluate the impacts of horizontal grid spacing on aerosol mass budget and aerosol-cloud-radiation interactions in E3SM. The findings provide insights into aerosol parameterization development and their dependence on model horizontal resolution. The methodology may help future studies explore the potential impacts of model resolutions on simulation results. Some findings may also apply to future E3SM simulations at convection-permitting scales, such as the enhancement in natural aerosol emissions due to stronger winds, the partitioning between large-scale and convective precipitation and associated wet scavenging, and improved aerosol activation in large-scale clouds.


By using the computational resources from the National Energy Research Scientific Computing Center, the researchers examined the resolution sensitivity of the simulated aerosol mass budget, aerosol-cloud interactions, and the effective radiative forcing of anthropogenic aerosols over the contiguous United States in E3SM v1 by comparing the nudged simulation results for 2016 at low- and high-resolution configurations using the regional refinement model (RRM) capability. The RRM configuration is almost identical to the global low-resolution configuration except for the high-resolution meshes over the contiguous United States for RRM. Results show that increasing resolution over the contiguous United States produces more natural dust, sea salt, and marine organic matter. The high-resolution model simulates stronger aqueous-phase production of sulfate due to increased cloud liquid water content while slightly less gas-phase chemical production of sulfate. In addition, the high-resolution model resolves more large-scale precipitation and produces less convective precipitation, leading to increased (or decreased) aerosol wet scavenging by large-scale (convective) precipitation. The high-resolution model also promotes aerosol activation and water vapor condensation, which produces more cloud droplets, a larger cloud droplet radius, and a larger cloud optical depth. Therefore, the aerosol indirect effect is stronger in the high-resolution model, leading to an increase in the effective radiative forcing of anthropogenic aerosols by about 12 percent.

PNNL Contact

Po-Lun Ma, Pacific Northwest National Laboratory, Po-Lun.Ma@pnnl.gov


This study was supported by the Department of Energy (DOE) Office of Science’s Biological and Environmental Research program as part of the Earth System Model Development program area through the Enabling Aerosol-cloud interactions at GLobal convection-permitting scalES (EAGLES) project. The research used high-performance computing resources from the Pacific Northwest National Laboratory (PNNL) Research Computing and resources of the National Energy Research Scientific Computing Center (NERSC), a DOE Office of Science User Facility located at Lawrence Berkeley National Laboratory, operated under contract no. DE-AC02-05CH11231.

Published: April 30, 2024

Li, J., Zhang, K., Hassan, T., Zhang, S., Ma, P.-L., Singh, B., Yan, Q., and Huang, H.: Assessing the sensitivity of aerosol mass budget and effective radiative forcing to horizontal grid spacing in E3SMv1 using a regional refinement approach, Geosci. Model Dev., 17, 1327–1347, https://doi.org/10.5194/gmd-17-1327-2024, 2024.
