A giant, inflatable structure designed to prevent flooding in subways was rolled out, literally, for media observers inside a full-scale, mock subway tunnel. As the video shows, in under five minutes it is nearly filled with pressurized air — creating a flexible but extremely strong barrier. Full inflation is complete in less than 12 minutes. The live demonstration continued with the plug holding back simulated floodwater at 11.5 pounds per square inch pushing against it.

"The big problem wasn't just designing the plug, but ensuring it could be stored without interfering with trains passing through their tunnels."

-Greg Holter

The Department of Energy's Pacific Northwest National Laboratory helped develop the Resilient Tunnel Plug in partnership with ILC Dover and West Virginia University for the Department of Homeland Security's Science and Technology Directorate. It's kind of like a large balloon, but infinitely stronger.

"This is one of those things where we had an idea that was pretty simple but we needed to take that concept to reality," PNNL engineer Greg Holter said. "The big problem wasn't just designing the plug, but ensuring it could be stored without interfering with trains passing through their tunnels."

The RTP, made from a liquid crystal polymer called Vectran®, was developed to provide security to transit systems as protection from flooding, primarily in subways, in the event of a terrorist attack or natural disaster. In the event of flooding, the plug would rapidly inflate, holding back a tunnel full of floodwater, keeping citizens and the transit system assets safe.

Learn more about the technology on DHS' website.
