Atmospheric Sciences & Global Change
Research Highlights

August 2018

Integrating Human System Dynamics Into Earth System Models

A review of modeling research on two-way interactions between human and Earth systems sheds light on system interactions and informs directions for future Earth system modeling research.

Earth system models
Researchers seek ways to more fully couple human system models into Earth system models as a means to explore a more comprehensive set of interactions, including impacts of the Earth system on human systems. Enlarge Image.
The Science

Historically, Earth system models (ESMs) have considered only limited, one-way interactions with human systems and human system modeling, with key human-caused drivers of the Earth system (such as industrial emissions and land use changes) supplied by external models. Increasingly, however, researchers are exploring ways to more fully couple human system models into ESMs as a means to explore a more comprehensive set of interactions, including impacts of the Earth system on human systems. Researchers at the U.S. Department of Energy's Pacific Northwest National Laboratory surveyed a broad set of relevant literature on fully coupled models with two-way feedbacks between the human and Earth systems.

The Impact

This review quantifies key results emerging from the literature on feedbacks between coupled human and Earth system models. It identifies limitations in the current literature, such as the small number of studies, and outlines future research directions for better incorporating human system models and dynamics into ESMs.

Summary

In this review, researchers surveyed the literature on modeling approaches that include two-way feedbacks (i.e., interactions) between human and Earth systems and quantified the direction and strength of feedbacks emerging in those models. They then analyzed the feedbacks in context of other, more frequently considered feedbacks in the Earth system, including processes such as wildfire and permafrost thaw. Though the team found that such feedbacks have the potential to alter both human and Earth systems, the number of studies that incorporate two-way interactions remains small.

Additional research, models, and studies are needed to robustly quantify the sign and magnitude of human-Earth system feedbacks. Integrating human systems into ESMs entails significant complexity and cost, and researchers should carefully assess the costs and benefits of doing so with respect to the object of study.

Acknowledgments

Sponsors: This research was supported as part of the Energy Exascale Earth System Model (E3SM) project, funded by the U.S. Department of Energy Office of Science, Biological and Environmental Research.

Research Area: Climate and Earth Systems Science

Research Team: Katherine Calvin and Ben-Bond Lamberty, PNNL (Joint Global Change Research Institute)

Reference: K. Calvin and B. Bond-Lamberty, "Integrated Human-Earth System Modeling-State of the Science and Future Directions." Environmental Research Letters 13, 063006 (2018). [https://doi.org/10.1088/1748-9326/aac642]
