July 2012

Mother Nature as a Wire Manufacturer

With computational models, scientists see how microbe directs electrons

Scientists elucidated the molecular details of electron transport along the 10-heme chains in the Shewanella oneidensis’ cytochrome (right) using complex, dynamic molecular simulations. Enlarge Image

Results: For the first time, each step an electron takes as it moves along a "wire" from a microbe's interior to the outside world is known, thanks to modeling by University College London and Pacific Northwest National Laboratory. The wire is a twisted molecule, known as a cytochrome. The cytochrome is made of 10 iron-based clusters, called hemes, held in a particular arrangement by a protein that serves as a backbone. The hemes are positioned end-to-end in a staggered cross, to comprise the electron transfer interface between the interior of Shewanella oneidensis, a bacteria found in the soil, and metals and minerals beyond the cell's wall.

"This is the first look at how nature would design a molecular wire for transport on nanometer length scales," said Dr. Kevin Rosso, a geochemist at PNNL and a corresponding author on the study.

Why It Matters: To understand how these microbes influence contaminated water and soil, as well as to answer the clamor for smaller and smaller computer circuits, scientists are looking to bacteria. Optimized over eons, bacteria are very proficient at moving electrons using molecular complexes. This study provides details about the molecules that move the electrons and how they work. It is opening doors to designing molecule-sized circuits and to research related to how these microbes affect contaminated water and soil.

Shewanella may send out tiny wires that contact metals and minerals. Within these wires are thought to be proteins containing hemes that pass electrons outward. In 2011, a collaborative team from the University of East Anglia and Pacific Northwest National Laboratory determined the structure of the first of these protein components. This research expands on that study, showing how the electrons hopscotch across the tiny wires.

Methods: Last year, the structure and other characteristics of the 10 hemes in the bacterial protein were established from experiment. The results appeared in Proceedings of the National Academy of Sciences of the United States of America. This year, Rosso and team wanted to determine exactly what was happening with the hemes as the electrons jump from one to the next, so they turned to computational modeling and simulation.

"Lab experiments can't go after that type of information," said Rosso. "From an experimental standpoint, the hemes all look alike; they can't isolate and identify one heme at a time. We can."

The team built large-scale computational simulations of the cytochrome that involved tens of thousands of atoms, allowing them to determine how easily the electrons were transferred heme to heme. Specifically, they wanted to know the redox potential of each iron-based complex, with the surrounding molecular environment and dynamics explicitly described. The redox potential is a measure of a molecule's tendency to acquire electrons. It turns out that the cytochrome's hemes are relatively balanced in their ability to pull electrons from each other, meaning that electrons do not strongly favor one direction over another. Further, under the right conditions, the protein looks able to turn the flow of electrons on and off, and might even be able to reverse the flow of electrons, based on subtle distortions in the molecular structure.

To verify the results, the simulations were run on two different supercomputers and then compared. The results agreed well and were recently published as a rapid communication in the Journal of the American Chemical Society.

What's Next? Having determined the structure and how the electrons hopscotch from heme to heme, the researchers are now studying electron flow over longer time scales. Further, they are studying at how changes in the cytochrome might alter the electron's passage.


Sponsors: Marian Breuer was funded by an IMPACT studentship co-sponsored by University College London and PNNL through the U.S. Department of Energy's Subsurface Biogeochemistry Research Science Focus Area program of DOE's Office of Biological and Environmental Research (BER). BER also sponsored the work by Kevin Rosso and Piotr Zarzycki. Jochen Blumberger was funded by the Royal Society through a University Research Fellowship.

User Facility: This work was carried out on HECToR (United Kingdom), to which access was granted via the Materials Chemistry Consortium, and on Chinook at EMSL (USA), a national scientific user facility sponsored by BER.

Research Team: Marian Breuer and Jochen Blumberger, University College London; Piotr Zarzycki, Polish Academy of Sciences; and Kevin Rosso, PNNL

Reference: M Breuer, P Zarzycki, Jochen Blumberger, and KM Rosso. 2012. "Thermodynamics of Electron Flow in the Bacterial Deca-heme Cytochrome MtrF." Journal of the American Chemical Society 134(24):9868-9871. DOI:10.1021/ja3027696.
