November 2017

Where Liquid Meets Air: Seeing the Details of Light, Dark, and Water

Technique gives detailed view into how certain polymers form, unlocking answers about nucleation

Journal cover showing water research with SALVI
The research graces the cover of Physical Chemistry Chemical Physics. Cover reproduced with permission of the authors and the Royal Society of Chemistry (see reference). Enlarge Image.

Imagine a tiny drop. It contains water, the fizzy antiseptic hydrogen peroxide, and a common, yellowish chemical called glyoxal. When the droplet is exposed to light, a cascade of reactions occurs, producing new materials. These reactions occur on the surface, where liquid meets air. Scientists didn't have many details about the reactions until Dr. Xiao-Ying Yu from DOE's Pacific Northwest National Laboratory and her colleagues took up the challenge. They got the details using an imaging mass spectrometer that typically boil liquids away in vacuum. They found that the reactions don't stop when the light fades. They also saw how the resulting products mixed on the surface and reacted with more than 40 water clusters.

"Computer models can track about 10 to 12 clusters," said Yu, the corresponding author on the study. "We observed over 40 clusters in liquid. We were able to see how the chemical products change the microenvironment, creating larger water clusters."

Why It Matters: Meeting the demand for energy through new fuels, energy efficiency and carbon sequestration requires knowing how materials form to, in turn, control that formation and produce materials by the boxcar and barrel. This study offers insights into how chemical building blocks -- glyoxal, water, and hydrogen peroxide -- chain together, or nucleate, to form materials. In addition, the work offers insights into nucleation reactions involving glyoxal in the air. In the atmosphere, these reactions lead to particles that affect cloud formation and climate.

Dr. Xiao-Ying Yu and SALVI
Xiao-Ying Yu and SALVI

Summary: Many of the steps are known in using glyoxal with hydrogen peroxide to form dicarboxylic acids and chains of hydrocarbons, known as oligomers. These oligomers are also the starting materials for troubling atmospheric aerosols, known as secondary organic aerosols. The problem was that not all of the steps were known and that one desirable instrument, secondary ion mass spectrometry (SIMS), couldn't be used to track the products formed. It wasn't possible to use SIMS on a liquid sample. That's where SALVI comes in. Formally known as the System for Analysis at the Liquid Vacuum Interface, SALVI lets imaging instruments such as SIMS study liquids exposed to air. With the SALVI and SIMS combination, researcher can follow the reactions in real time and in a realistic environment.

The chemical nucleation reaction is kick started by ultraviolet light. With the SALVI, which is small enough to fit in the palm of your hard, set inside the SIMS, the team examined what happened when the chemicals received ultraviolet light for up to 8 hours.

But the team also wanted to know what happened when the lights went out. They looked at how the reactions progressed when held in the dark for up to 8 hours. Different reactions occurred in the dark than in the light. Surprisingly, the team found the reactions didn't stop when the energy source, the light, did.

Using SALVI in SIMS, located at DOE's EMSL, the team also created a chemical spatial map of the air-liquid interface. That is, they identified the chemicals and their location in tiny divots on the liquid's surface. "In models, it isn't easy to see what mixes at the surfaces," said Yu. "We provided a glimpse of what's really at the surface -- or the mixing state that is important to interfacial changes."

As an added bonus, SALVI let the team observe 43 to 44 water clusters in the sample. Typically, computational models run on supercomputers model 10 to 12 water clusters. In seeing the clusters, the team determined how the chemical products created an increasingly hydrophobic surface that, in turn, pushed the water together and created larger water clusters. "SALVI is the only technique that can provide molecular mapping of water clusters and ion clusters in liquid to the best of our knowledge," said Yu.

Acknowledgments

Sponsors: The Pacific Northwest National Laboratory Materials Synthesis and Simulation across Scales (MS3) Initiative and the Earth and Biological Sciences Directorate Mission Seed Laboratory Directed Research and Development fund.

Research Area: Materials Science

User Facility: EMSL, a national scientific user facility sponsored by the DOE's Office of Biological and Environmental Research and located at Pacific Northwest National Laboratory

Research Team: Xiao Sui, Shandong University and Pacific Northwest National Laboratory (PNNL); Fei Zhang, Shanghai Key Laboratory of Atmospheric Particle Pollution and Prevention and PNNL; Jianmin Chen, Environment Research Institute and Shanghai Key Laboratory of Atmospheric Particle Pollution and Prevention; Yufan Zhou, Zihua Zhu, and Xiao-Ying Yu, PNNL

Reference: Sui X, Y Zhou, F Zhang, J Chen, Z Zhu, and XY Yu. 2017. "Deciphering the Aqueous Chemistry of Glyoxal Oxidation with Hydrogen Peroxide Using Molecular Imaging." Physical Chemistry Chemical Physics 19:20357-20366. DOI: 10.1039/c7cp02071f
